Efficiently Powerful
With high full turn tipping loads, powerful breakout forces and increased engine power the M Series delivers a balanced solution for all customer applications.
Work Made Easy
The Cat® Optimized Z-bar Loader linkage combines the digging efficiency of a traditional Z-bar with tool carrier capabilities for great performance and versatility. With parallel lift and high tilt forces throughout the working range you can safely and confidently handle loads with precise control. Multi-function work has never been easier with dedicated pumps for each system, allowing the operator to simultaneously lift, steer and drive without compromise.
Enjoy All Day Comfort
A spacious, safe, quiet and comfortable operator environment helps keep you relaxed and productive throughout the day. Experience superior all around visibility with a pillarless front windshield, clean hydraulic linesrouting as well as in-line engine mounting for excellent rear visability. Electro-hydraulic controls featuring low effort joystick for lift and tilt functions along with integrated Forward/Neutral/Reverse switch, differential lock trigger and optional third and fourth auxiliary functions.
- Climate controlled cab with heated rear glass
- Information at a glance with large LCD display on front console
- Heated seat option for added comfort
- Exclusive electro-hydraulic cylinder snubbing
- An extra eye on the job site with optional* rearview camera capability
*Standard in Europe.
Hydraulic and Controls
State of the art electro-hydraulic system provides low effort, fine control with fast cycle times. All-in-one joystick helps keep eyes on the work. Operator can adjust machine responsiveness with the push of a button, which allows the operator to set up the machine exactly the way they want it based on the application.
Tuned Drivetrain
Smooth shifting and powerful acceleration is matched with modulated hydrostatic braking in the inching/braking pedal, creating a rhythm for material moving. Creeper and electronic engine speed control makes broom and snow blower work easy. Operator tunes between smooth or aggressive shifting with the push of a button.
